MXC to MXC Cable
The newest MXC optical interconnect solutions utilize the expanded-beam MT technology to provide cutting-edge high-density interconnection. It provides a direct card edge interface to embedded optical engines for a wide variety of equipment interface applications.
Fiberwe provide fully-customized fiber assemblies using the newest MXC connector. Our MXC to MXC cable assemblies are offered in highly customizable configuration, customer can specify MXC-plug or MXC-receptacle on either ends, with choices of round cable or bare ribbon cable in specific lengths as required.
- Cutting-edge high-density, 132 MXC receptacle fit into a 19" 1U panel, increase 40% faceplate space and 59% PCB area
- Less sensitive to debris and contamination, Recessed ferrule with expanded-beam MT technology
- Reduces cost, complexity and footprint, Eliminated the traditional adapter and reduced component count
- High flexibility in operation and installation, Convenient conversion from MXC interface to MTP/MPO for connecting CXP or other active optical modules
- Terabit per second bandwidth capability, 64 fibers each transferring data at 25Gbps, allowing 1.6 TBit/s per connector
- Telecommunication Hubs and Servers
- Storage Facilities
- Open-Compute Architectures
- Cloud Data Centers
- Switching and routing fabrics
