MTP Cassette
MTP/MPO cassettes are a kind of breakout/fanout MPO cable assembly packaged in Plug-and-Play (PnP) LGX cassette boxes with adapters outside, ideal for connecting multi-fiber MTP/MPO trunk cables and splitting them out to various patch cables. Each cassette comes fully populated internally with pre-terminated and tested MPO hydra breakout/fanout cables, designed for fast and easy field installation with minimal training.
These cassettes meet the demands of 10G/25G Ethernet, higher speed 40G/100G Ethernet, and can be used for standards-compliant cable plant migration from 10G/25G to 40G/100G. The Fiberwe MTP/MPO cassettes are fully configurable, available with a variety of cable and connector combinations, including connector/adapter type, and jacket material. With highly integrated design and manufacturing capability, Fiberwe provides customized MTP/MPO cassettes which are 100% tested to deliver optimal performance and reliability.
- Insertion loss type available in Standard, Elite / Low Loss
- Fiber count available in 1*8, 1*12, 2*12, 1*24, 2*24
- MTP/MPO connector type available in Male, Female
- Fiber type available in SM (G652D, G657A1, G657A2), MM (OM1, OM2, OM3, OM4)
- Cable jacket type available in Hytrel, OFNR, LSZH, OFNP
- Multi-fiber connector type available in MTP, MPO with APC or PC polishing type
- Single-fiber connector type available in LC, SC with APC or UPC polishing type
- High-density and small design for easy and fast installation
- Field connections with guaranteed quality and simplify fiber routing
- Modular system management with easy reconfiguration for moves, adds, and changes
- Data Center Interconnect
- Backbone Installations
- Telecommunication Networks
- Broadband/CATV Networks
- LAN/WAN Premise
