MTP Loopback
MTP/MPO Loopback is offered in female design with an economical solution for providing a stable and convenient means of network testing and diagnosing.
The loopback structure supports the direct mating with MTP/MPO adapter and parallel optical device (POD) such as a Quad Small Form Factor Pluggable (QSFP),and it also can simulate network distances within the device.
- Ruggedized plastic housing design, High durability with stable performance
- Bend Insensitive fiber with low loss connector, High precision alignment with superior optical loss
- Options for OM3 and OM4 fiber mode, Simulates network distances within the device
- Options for 12-or 24-Fibers MTP/MPO interface, Applicable in any MTP/MPO adaptor and other device ports
- Customized optical routing needs, Caters for different applications such as testing devices, CATV, sensor, etc.
- 40GbE QSFP+ Optical Testing
- Research and Development
- Manufacturing Test
- Troubleshooting
- Quality Control
- Training
